The "J1939 CAN Pulse Converter", was designed to take advantage of the information present in the engine/vehicle Electronic Control Module of today's electronic engines and other systems, allowing pulse driven equipment such as trip recorders, tachographs, etc., to work directly from electronic engines control modules.
The J1939 CAN Pulse Converter is compatible with the CANBUS J1939 and provides appropriate pulse outputs of Speed, RPM, Fuel and Fault Codes, directly to trip recorders, tachographs, speedometers, tachometers, etc., eliminating the need for additional sensors, as well as yielding significant savings where real time fuel inputs are desired, by eliminating the need for expensive mechanical fuel flow sensors.
Other features of the SDL are:
- Automatically select between 250 kb/s and 500 kb/s bus speeds.
- Default calibration values are provided eliminating the need for adjustment.
- Other calibration values are available if required
- Fault codes
- Small dimensions: 101.62mm x 76.21mm x 38.10mm (4" x 3" x 1.5")
